基于fine tune的图像分类(百度分狗竞赛)
By 苏剑林 | 2017-10-13 | 28576位读者 |前两年百度的大数据竞赛都是自然语言处理方面的,今年画风一转,变成了图像的细颗粒度分类,赛题内容就是将宠物狗归为100类中的其中一类。这个任务本身是很平凡的,做法也很常规,无外乎就是数据扩增、imagenet模型的fine tune、模型集成三个方面。笔者并不擅长于模型集成,只做了前面两个步骤,成绩也非常一般(准确率80%上下)。但感觉里边的某些代码可能对读者有帮助,遂共享一翻。下面结合着代码来讲解。
比赛官网(随时有失效的可能):http://js.baidu.com
模型 #
模型主要用tensorflow+keras实现。首先自然是导入各种模块
#! -*- coding:utf-8 -*-
import numpy as np
from scipy import misc
import tensorflow as tf
from keras.applications.xception import Xception,preprocess_input
from keras.layers import Input,Dense,Lambda,Embedding
from keras.layers.merge import multiply
from keras import backend as K
from keras.models import Model
from keras.optimizers import SGD
from tqdm import tqdm
import glob
np.random.seed(2017)
tf.set_random_seed(2017)
然后是模型,基础模型是Xception,然后使用了GLU激活函数来压缩特征,最后接softmax分类,此外,还添加了center loss和auxiliary loss(直连边)作为辅助,这两项可以看成是正则项。
img_size = 299 #定义一些参数
nb_classes = 100
batch_size = 32
feature_size = 64 #个人认为要用center loss,特证数要比nb_classes小才有意义
input_image = Input(shape=(img_size,img_size,3))
base_model = Xception(input_tensor=input_image, weights='imagenet', include_top=False, pooling='avg') #基础模型是Xception,加载预训练的imagenet权重,但不包括最后的全连接层
for layer in base_model.layers: #冻结Xception的所有层
layer.trainable = False
dense = Dense(feature_size)(base_model.output)
gate = Dense(feature_size, activation='sigmoid')(base_model.output)
feature = multiply([dense,gate]) #以上三步构成了所谓的GLU激活函数
predict = Dense(nb_classes, activation='softmax', name='softmax')(feature) #分类
auxiliary = Dense(nb_classes, activation='softmax', name='auxiliary')(base_model.output) #直连边分类
input_target = Input(shape=(1,))
centers = Embedding(nb_classes, feature_size)(input_target)
l2_loss = Lambda(lambda x: K.sum(K.square(x[0]-x[1][:,0]), 1, keepdims=True), name='l2')([feature,centers]) #定义center loss
训练策略方面,分三步训练:
1、冻结Xception的所有参数,只训练额外添加的全连接层和center loss部分,用adam训练;
2、放开Xception的两个block,换用sgd微调;
3、去除大部分的数据扩增,继续用sgd微调。
代码如下:
model_1 = Model(inputs=[input_image,input_target], outputs=[predict,l2_loss,auxiliary])
model_1.compile(optimizer='adam',
loss=['sparse_categorical_crossentropy',lambda y_true,y_pred: y_pred,'sparse_categorical_crossentropy'],
loss_weights=[1.,0.25,0.25],
metrics={'softmax':'accuracy','auxiliary':'accuracy'})
model_1.summary() #第一阶段的模型,用adam优化
for i,layer in enumerate(model_1.layers):
if 'block13' in layer.name:
break
for layer in model_1.layers[i:len(base_model.layers)]: #这两个循环结合,实现了放开两个block的参数
layer.trainable = True
sgd = SGD(lr=1e-4, momentum=0.9) #定义低学习率的SGD优化器
model_2 = Model(inputs=[input_image,input_target], outputs=[predict,l2_loss,auxiliary])
model_2.compile(optimizer=sgd,
loss=['sparse_categorical_crossentropy',lambda y_true,y_pred: y_pred,'sparse_categorical_crossentropy'],
loss_weights=[1.,0.25,0.25],
metrics={'softmax':'accuracy','auxiliary':'accuracy'})
model_2.summary() #第二阶段的模型,用sgd优化
model = Model(inputs=input_image, outputs=[predict,auxiliary]) #用来预测的模型
model.compile(optimizer='adam', loss='sparse_categorical_crossentropy', metrics=['accuracy'])
扩增 #
接着,是关于本次竞赛的数据准备,官方最后提供了1.8万张训练图片。
import pandas as pd
train_txt = pd.read_csv('../train.txt', delimiter=' ', header=None)[[0,1]] #txt记录的是每张图片的类别
myid2typeid = dict(enumerate(train_txt[1].unique())) #txt记录的类别是有空的,需要映射为连续的
typeid2myid = {j:i for i,j in myid2typeid.items()}
train_txt[1] = train_txt[1].apply(lambda s: typeid2myid[s])
train_txt = train_txt.sample(frac=1) #打乱训练数据集
train_txt.index = range(len(train_txt))
train_imgs = list(train_txt[0])
train_txt = dict(list(train_txt.groupby(1)))
train_data,valid_data = {},pd.DataFrame()
train_frac = 0.9 #划分一个验证集
for i,j in train_txt.items(): #每个类中拿出10%作为验证集
train_data[i] = j[:int(len(j)*train_frac)]
valid_data = valid_data.append(j[int(len(j)*train_frac):], ignore_index=True)
接下来是一些数据扩增代码,纯手写,没用任何现成的库,好处是自定义强。当然,这些数据扩增手段是否每一个对问题都有提升,这是不确定的。
#定义插值方式,当初将它定义为函数,本是希望随机使用不同的插值方式,这也是一种数据扩增的方式,但后来去掉了随机性。
def interp_way():
return 'nearest'
def random_reverse(x): #随机水平翻转,概率是0.5
if np.random.random() > 0.5:
x = x[:,::-1]
return x
def random_rotate(x): #随机旋转,幅度是-10~10角度
angle = 10
r = (np.random.random()*2-1)*angle
return misc.imrotate(x, r, interp=interp_way())
def Zoom(x, random=True): #缩放函数
if random: #随机缩放
r = np.random.random()*0.4+0.8 #随机缩放比例是0.8~1.2
img_size_ = int(img_size*r)
x = misc.imresize(x, (img_size_,img_size_), interp=interp_way())
idx,idy = np.random.randint(0, np.abs(img_size_-img_size)+1, 2)
if r >= 1.: #如果是放大,则随机截取一块
return x[idx:idx+img_size,idy:idy+img_size]
else: #如果是缩小,则随机读取一张训练集,然后把缩小后的图像贴上去
x_ = misc.imresize(misc.imread('../train/%s.jpg'%np.random.choice(train_imgs)), (img_size,img_size))
x_[idx:idx+img_size_,idy:idy+img_size_] = x
return x_
else: #不随机的话,直接缩放到标准尺寸
x = misc.imresize(x, (img_size,img_size), interp=interp_way())
return x
#下面是实现两张同类照片随机拼接的代码,通过“同类拼接仍为同类”的思想,构造更多样的样本
#共可以提出4中不同的拼接方式:两种对角线拼接、水平拼接、垂直拼接,4种方式随机选择
cross1 = np.tri(img_size,img_size)
cross2 = np.rot90(cross1)
cross1 = np.expand_dims(cross1, 2)
cross2 = np.expand_dims(cross2, 2)
def random_combine(x,y):
r,idx = np.random.random(),np.random.randint(img_size/4, img_size*3/4)
if r > 0.75:
return np.vstack((x[:idx],y[idx:]))
elif r > 0.5 :
return np.hstack((x[:,:idx],y[:,idx:]))
elif r > 0.25:
return cross1*x + (1-cross1)*y
else:
return cross2*x + (1-cross2)*y
M1 = np.ones((img_size,img_size))
M1[:img_size/2,:img_size/2] = 0
M2 = np.expand_dims(np.rot90(M1, 1), 2)
M3 = np.expand_dims(np.rot90(M1, 2), 2)
M4 = np.expand_dims(np.rot90(M1, 3), 2)
M1 = np.expand_dims(M1, 2)
def random_mask(x, p=0.5): #随机把图片遮掩掉1/4,类似dropout的做法
r = np.random.random()
s = p/4
if r > 1-s:
return M1*x
elif r > 1-s*2:
return M2*x
elif r > 1-s*3:
return M3*x
elif r > 1-s*4:
return M4*x
else:
return x
def center_crop(x): #只截取图像中心部分,这是预测的时候用到的。
idx = np.abs(x.shape[1]-x.shape[0])/2
if x.shape[0] < x.shape[1]:
return x[:, idx:x.shape[0]+idx]
else:
return x[idx:x.shape[1]+idx, :]
def random_imread(img_path, rotate=True): #综合上面的数据扩增函数来写的读图像函数
img = misc.imread(img_path)
img = center_crop(img)
if rotate:
img = Zoom(random_rotate(img), True)
else:
img = Zoom(img, True)
return random_reverse(img).astype(float)
def just_imread(img_path): #不做数据扩增的读图像函数
img = misc.imread(img_path)
img = center_crop(img)
img = Zoom(img, False).astype(float)
return img
迭代器 #
我们写迭代器,用来生成训练和测试的数据批:
result_filename = '__test_result_2_2245.txt' #这是预测结果文件,迁移学习的时候用
choice_weights = np.array([1.*len(train_txt[i]) for i in range(nb_classes)])
choice_weights /= choice_weights.sum() #定义每个类的权重
def train_data_generator(stage,train_data): #训练集的generator,训练过程中用
if stage == 'Train_DA': #训练阶段,数据扩增
_ = {}
for i,j in train_data.items():
j_ = j.copy()
j_[0] = zip(j[0].sample(frac=1),j[0].sample(frac=1))
_[i] = j.append(j_, ignore_index=True)
train_data = _ #以上几步预先整理好随机拼接的图片对
while True:
_ = np.random.choice(nb_classes, batch_size/2, False, choice_weights) #先选类
batch = pd.DataFrame()
for idx in _: #每个类选两个样本
batch = batch.append(train_data[idx].sample(2), ignore_index=True)
x,y = [],[]
for i,(img_path,myid) in batch.iterrows():
if len(img_path) == 2: #这是随机拼接的情形
img1,img2 = just_imread('../train/%s.jpg'%img_path[0]),just_imread('../train/%s.jpg'%img_path[1])
x.append(random_combine(img1, img2)) #随机拼接就不做其他的数据扩增了
else:
img = random_mask(random_imread('../train/%s.jpg'%img_path)) #完整的随机数据扩增
x.append(img)
y.append([myid])
x,y = np.array(x),np.array(y)
yield [preprocess_input(x),y], [y,y,y] #构成keras模型所需要的输出
elif stage == 'Train': #训练阶段,减少数据扩增
while True:
_ = np.random.choice(nb_classes, batch_size/2, False, choice_weights)
batch = pd.DataFrame()
for idx in _:
batch = batch.append(train_data[idx].sample(2), ignore_index=True)
x,y = [],[]
for i,(img_path,myid) in batch.iterrows(): #随机遮掩和随机拼接都被去除
img = random_imread('../train/%s.jpg'%img_path, False)
x.append(img)
y.append([myid])
x,y = np.array(x),np.array(y)
yield [preprocess_input(x),y], [y,y,y]
elif stage == 'Transfer_DA': #迁移学习阶段,代码跟训练阶段是一样的,只不过加入了测试集的预测结果
train_data = train_txt.copy()
test_result = pd.read_csv(result_filename, delimiter='\t', header=None)[[1,0]]
test_result.columns = [0,1]
test_result[1] = test_result[1].apply(lambda s: typeid2myid[s])
for i,j in test_result.groupby(1):
train_data[i] = train_data[i].append(j, ignore_index=True)
_ = {}
for i,j in train_data.items():
j_ = j.copy()
j_[0] = zip(j[0].sample(frac=1),j[0].sample(frac=1))
_[i] = j.append(j_, ignore_index=True)
train_data = _
while True:
_ = np.random.choice(nb_classes, batch_size/2, False, choice_weights)
batch = pd.DataFrame()
for idx in _:
batch = batch.append(train_data[idx].sample(2), ignore_index=True)
x,y = [],[]
for i,(img_path,myid) in batch.iterrows():
if len(img_path) == 2:
#人工把测试集的所有图片复制一份到train目录下
img1,img2 = just_imread('../train/%s.jpg'%img_path[0]),just_imread('../train/%s.jpg'%img_path[1])
x.append(random_combine(img1, img2))
else:
img = random_mask(random_imread('../train/%s.jpg'%img_path))
x.append(img)
y.append([myid])
x,y = np.array(x),np.array(y)
yield [preprocess_input(x),y], [y,y,y]
elif stage == 'Transfer':
train_data = train_txt
test_result = pd.read_csv(result_filename, delimiter='\t', header=None)[[1,0]]
test_result.columns = [0,1]
test_result[1] = test_result[1].apply(lambda s: typeid2myid[s])
for i,j in test_result.groupby(1):
train_data[i] = train_data[i].append(j, ignore_index=True)
while True:
_ = np.random.choice(nb_classes, batch_size/2, False, choice_weights)
batch = pd.DataFrame()
for idx in _:
batch = batch.append(train_data[idx].sample(2), ignore_index=True)
x,y = [],[]
for i,(img_path,myid) in batch.iterrows():
img = random_imread('../train/%s.jpg'%img_path, False)
x.append(img)
y.append([myid])
x,y = np.array(x),np.array(y)
yield [preprocess_input(x),y], [y,y,y]
def valid_data_generator(): #验证集的generator,训练过程中用
x,y = [],[]
for i,(img_path,myid) in valid_data.iterrows():
img = just_imread('../train/%s.jpg'%img_path)
x.append(img)
y.append(myid)
if len(x) == batch_size:
yield preprocess_input(np.array(x)), np.array(y)
x,y = [],[]
if x:
yield preprocess_input(np.array(x)), np.array(y)
test_imgs = glob.glob('../test/*.jpg')
test_imgs = [i.replace('../test/','').replace('.jpg','') for i in test_imgs]
def test_data_generator(): #测试集的generator,生成结果文件用
x = []
for img_path in test_imgs:
img = just_imread('../test/%s.jpg'%img_path)
x.append(img)
if len(x) == batch_size:
yield preprocess_input(np.array(x))
x = []
if x:
yield preprocess_input(np.array(x))
训练 #
首先我们训练模型,然后用模型来预测,接着把预测结果和训练集混合一起训练,然后得到新的预测结果,可以再把新的结果再混合训练,逐步迭代。这是一种迁移学习的思想,可以提升效果约0.5%~1%。
另外,因为模型有一个预测,一个是用GLU的特征预测,一个是直接用Xception的特征预测,我们可以把两个预测结果加权平均,来提升预测效果,而权重则是由验证集决定
if __name__ == '__main__':
#训练过程
train_epochs = 30
alpha = 0.5
for i in range(train_epochs):
print 'train epoch %s working ...'%i
if i < 10: #第一阶段训练
model_1.fit_generator(train_data_generator('Train_DA',train_data), steps_per_epoch=200, epochs=3)
if i < 9:
continue
elif i < 20: #第二阶段训练
model_2.fit_generator(train_data_generator('Train_DA',train_data), steps_per_epoch=200, epochs=3)
else: #第三阶段训练
model_2.fit_generator(train_data_generator('Train',train_data), steps_per_epoch=200, epochs=3)
valid_x_0 = []
valid_x_1 = []
valid_y = []
for x,y in tqdm(valid_data_generator()):
_ = model.predict(x)
valid_x_0.append(_[0])
valid_x_1.append(_[1])
valid_y.append(y)
valid_x = np.vstack(valid_x_0),np.vstack(valid_x_1)
valid_y = np.hstack(valid_y)
total = 1.*len(valid_x[0])
right_0 = (valid_y == valid_x[0].argmax(axis=1)).sum()
right_1 = (valid_y == valid_x[1].argmax(axis=1)).sum()
acc_0 = right_0/total
acc_1 = right_1/total
right_2 = [(valid_y == ((h/100.)*valid_x[0]+(1-h/100.)*valid_x[1]).argmax(axis=1)).sum() for h in range(101)] #枚举搜索最佳权重
acc_2 = np.max(right_2)/total
alpha = np.argmax(right_2)/100.
print 'epoch %s, acc_0 %s, acc_1 %s, acc_2 %s'%(i, acc_0, acc_1, acc_2)
model_1.save_weights('main_%s_%s_%s_%s_%s.model'%(i, int(acc_0*10000), int(acc_1*10000), int(acc_2*10000), int(alpha*10000)))
#迁移过程,迁移过程不能和训练过程同时跑,一般是上面的训练过程跑完了,然后设置上面的train_epochs=0,更改下面的train_epochs=30,然后重新运行脚本
train_epochs = 30*0
if train_epochs > 0:
model_1.load_weights('__main_29_8165_8075_8165_10000_2289.model')
for i in range(train_epochs):
print 'transfer epoch %s working ...'%i
if i < 10:
model_2.fit_generator(train_data_generator('Transfer_DA',train_data), steps_per_epoch=200, epochs=3)
elif i < 20:
model_2.fit_generator(train_data_generator('Transfer',train_data), steps_per_epoch=200, epochs=3)
else:
model_1_.fit_generator(train_data_generator('Train',train_data), steps_per_epoch=200, epochs=3)
model_1.save_weights('main_t1_%s.model'%i)
#测试过程,生成三份预测结果,可以分别提交比较哪个更准确
test_result_0 = []
test_result_1 = []
test_result_2 = []
for x in tqdm(test_data_generator()):
_ = model.predict(x)
test_result_0.extend([myid2typeid[i] for i in _[0].argmax(axis=1)])
test_result_1.extend([myid2typeid[i] for i in _[1].argmax(axis=1)])
test_result_2.extend([myid2typeid[i] for i in (alpha*_[0]+(1-alpha)*_[1]).argmax(axis=1)])
test_result_0 = pd.DataFrame(test_result_0)
test_result_0[1] = test_imgs
test_result_0.to_csv('test_result_0.txt', index=None, header=None, sep='\t')
test_result_1 = pd.DataFrame(test_result_1)
test_result_1[1] = test_imgs
test_result_1.to_csv('test_result_1.txt', index=None, header=None, sep='\t')
test_result_2 = pd.DataFrame(test_result_2)
test_result_2[1] = test_imgs
test_result_2.to_csv('test_result_2.txt', index=None, header=None, sep='\t')
总结 #
尽管文章很长,但多数只是代码,而且从效果来看就是一个baseline,仅供读者入门学习,高手请留言指教,谢谢。
完整代码请点击:https://github.com/bojone/baidu_dog_classifier
转载到请包括本文地址:https://spaces.ac.cn/archives/4611
更详细的转载事宜请参考:《科学空间FAQ》
如果您还有什么疑惑或建议,欢迎在下方评论区继续讨论。
如果您觉得本文还不错,欢迎分享/打赏本文。打赏并非要从中获得收益,而是希望知道科学空间获得了多少读者的真心关注。当然,如果你无视它,也不会影响你的阅读。再次表示欢迎和感谢!
如果您需要引用本文,请参考:
苏剑林. (Oct. 13, 2017). 《基于fine tune的图像分类(百度分狗竞赛) 》[Blog post]. Retrieved from https://spaces.ac.cn/archives/4611
@online{kexuefm-4611,
title={基于fine tune的图像分类(百度分狗竞赛)},
author={苏剑林},
year={2017},
month={Oct},
url={\url{https://spaces.ac.cn/archives/4611}},
}
November 4th, 2021
您好 想了解一下您运行这个的python环境以及tensorflow、keras版本?看到后可以帮忙解答一下么
当时应该是python2.7吧,可能是keras 2.2.4,tf忘记了,估计是1.8
